2026 John Deere Ag 610 Integral Chisel Plow

2026 John Deere AG 610 Integral Chisel Plow

Integral Chisel Plow

• Offers a variety of sizes
• Implement warning lights enable safe transport
• Shovels and attaching hardware
• Sweeps and attaching hardware

Features May Include:

Offers a variety of sizes and excellent residue flow

• The 610 Chisel Plow is available in a variety of sizes to help match tractor horsepower and work designs.

Strong mainframe withstands demanding field conditions

• The 610 Chisel Plow features a large 102-mm x 102-mm (4-in. x 4-in.) tubular steel mainframe.
• Welded construction adds the inner strength that withstands twisting and pulling through demanding field conditions.

Choice of rigid, TruPosition™, and Tru-Depth™ standards

The rigid standard:

• Is 32 mm x 51 mm x 711 mm (1.25 in. x 2 in. x 28 in.)
• Design is suited for fields having few obstructions
• Will till to 203 mm (8 in.) deep
• Good clearance to handle heavy trash
  • 711-mm (28-in.) underframe
  • 305-mm (12-in.) spacing

The TruPosition standard:

• Cast pivot assembly holds shank firm while working in the soil
• Is 32 mm x 51 mm x 711 mm (1.25 in. x 2 in. x 28 in.)
• Shank is replaceable without disassembly of the standard assembly
• Trip action is suited for fields having rocks or other obstructions
  • 550-lb trip 711-mm (28-in.) standard will till to 203 mm (8 in.) deep
  • 711-mm (28-in.) underframe
  • Trip height of 254 mm (10 in.) for good clearance
• Slotted lower hole to aid in removing ground-engaging tools

The Tru-Depth standard:

• Cast pivot assembly holds the shank firm while working in the soil
• 51 mm x 32 mm x 813 mm (2 in. x 1.25 in. x 32 in.); edge bent for extra strength
• Designed to work in rocky ground and heavy draft conditions
  • Will till to 305 mm (12 in.) deep
  • Trip height of 279 mm (11 in.)
  • 568-kg (1250-lb) trip force
• Excellent clearance to handle heavy trash
  • 813-mm (32-in.) underframe
  • 305-mm (12-in.) spacing

Implement warning lights enable safe transport

• An implement warning light harness with a turn-signal module for two amber and two red lights are included as standard equipment for safe transport on roads.

The implement warning light harness requires one of the following:

• Category 2, 3-point hitch with or without Quik-Coupler

• Category 3 and 3N, 3-point hitch with or without Quik-Coupler

Horsepower requirements

• The rigid and TruPosition™ standards require engine horsepower of 6 hp per ft to 10 hp per ft.
• The Tru-Depth™ standard requires engine horsepower of 6 hp per ft to 14 hp per ft.
