2024 Art's Way X900 Manure Spreaders

2024 ART´S WAY X900 MANURE SPREADERS

BIG BOX, BIG SPREAD

The 900 cubic feet manure spreader is made for the big haulers. Those that are doing their own hauling and are taking too many trips out of the lot, need this one. With a box length of 31 feet, easily maneuver in and out of gates. Operate your floor chain speed and gate height to achieve the amount per acre for best nutrient management.

CAPACITY

Wheel hubs are the center for the durability of our boxes. Rated at 16,000 pounds per hub, the X900 can carry 54,000 pounds of manure. The box has a heaped capacity of 909 cubic feet.

WHEELS AND TIRES

The X900 Manure Spreader comes standard with a tandem axle. Choose Used Military tires or upgrade to a 600 series flotation tire option to minimize field compaction.

POWER

This size of spreader requires a 180-200 hp tractor. In this range, you can choose either a “small” 1-3/8 1000 RPM PTO or a “large” 1-3/4″ 1000 RPM PTO to make best use of your equipment.

SPREAD

The beaters are a model SRT18 angled underneath the floor to give maximum sizing and spread width.

DEPENDABLE

Our 88C chain boasts a limited lifetime warranty so you know you are always covered while in use. Our unique reversible chain feature gives you the opportunity to move the load away from the beaters to remove any foreign objects. Robust all tube steel slats provide additional durability while moving more and more manure.

RUGGED BOX BUILD

Densilite floors have minimal thermal expansion and contraction for less cracking and buckling with temperature changes. Better yet, it creates a slick surface for enhanced material flow. 2 inch uprights on 2 foot centers provide a strong structure for hauling.

FILL QUICKLY WITH A SKID STEER

Easy filling with low loading heights of 94 inches on our X900 with used military tires. The flared sides allow you to easily load material from the side over the wheel to decrease material loss and load time.

TRANSPORT SAFETY

Bright LED lights, a strong safety chain and convenient heavy-duty jack make you more visible and secure on the road. Move manure wisely.

OPERATOR PROTECTION

A heavy-duty rock guard is mounted on the front for maximum protection. Because safety is a front and back proposition.

OPERATOR CONVENIENCE

Slip resistant and color-coded hydraulic grips make hooking up a breeze. A bolt tensioning system allows for in-the-field chain adjustment. Grease points maintain smooth machine operation and can be easily accessed.

OPTIONAL RAVEN RATE CONTROL

Need precise application and records? More states are requiring operators to carry records for 7 years on where and how much manure they applied to their fields. This is a breeze with the optional Raven Rate Control system. Enter in the amount you want to spread per acre, set your end gate and away you go. It monitors PTO, floor chain speed, and senses the gate height to keep your spread consistent across the field. The system uses our optional integrated weighbars in the axles and hitch to monitor load weight while spreading.
